Straight Line Wire Drawing Machine LZ9/1200+Spool Take-up Machine GS 1250

The Straight Line Wire Drawing Machine LZ9/1200+Spool Take-up Machine GS 1250 is a comprehensive solution for wire drawing and winding operations. The LZ9/1200 machine efficiently reduces wire diameter, while the GS 1250 spool take-up machine ensures proper winding and packaging. This combination offers high productivity and precise control, suitable for industries such as steel, automotive, and electrical, where quality wire production is crucial. Trust us as your reliable straight line wire drawing machine manufacturer and let us contribute to the success of your business. Contact us today to discuss your wire drawing machine requirements!

Specifications of Straight Line Wire Drawing Machine LZ9/1200+Spool Take-up Machine GS 1250

ItemUnitLZ9/1200-1000LZ9/1000-800LZ10/800LZ10/600(560)LZ10/450(400)
Diameter of capstanmm1200-10001100-800800(700)600(560)450(400)
Drawing timestime99101010
Maximum diameter of inlet wiremmφ14-φ10φ10-φ8φ9-φ6.5φ6.5-φ5.5φ4.5-φ2.5
Minmum diameter of oulet wiremmφ5-φ3.5φ3.5-φ2.8φ2.8-φ2.0φ2.0-φ1.7φ1.4-φ0.8
Drawing line speedm/min300360480720840
Inlet tensile strengthMpa≤1300≤1300≤1300≤1300≤1300
Total compression rate%87.2487.7590.5390.5390.32
Average compression rate%20.4520.8212120.83
Motor powerKw110-7590-4575-3737-2215-7.5


Characteristics of Straight Line Wire Drawing Machine LZ9/1200 And Spool Take-up Machine GS 1250

The Straight Line Wire Drawing Machine LZ9/1200 and the Spool Take-up Machine GS 1250 are essential components of wire manufacturing processes. Here are three characteristics that differentiate these two machines:



Straight Line Wire Drawing Machine LZ9/1200:


Drawing Process: LZ9/1200 is primarily designed for the wire drawing process, where it reduces the diameter of wire by pulling it through a series of drawing dies. It's focused on the wire reduction and precision aspect of wire manufacturing.


High Drawing Speed: This straight line wire drawing machine is capable of high drawing speeds, making it suitable for producing large quantities of wire quickly. It's often used in applications where wire needs to be rapidly processed.


Precision and Surface Finish: Straight line wire drawing machine LZ9/1200 is known for its ability to provide precise wire diameter control and a smooth surface finish. This is crucial in industries that require wires with specific tolerances and high-quality surface finishes.



Spool Take-up Machine GS 1250:


Take-up and Packaging: GS 1250 is a spool take-up machine, specialized in winding the drawn wire onto spools or drums. Its primary function is to efficiently package the wire for storage, transportation, or further processing.


Variable Spool Sizes: This machine is adaptable to various spool sizes, allowing manufacturers to package wire onto different-sized spools based on their requirements. It offers flexibility in wire packaging.


Tension Control: GS 1250 is equipped with tension control mechanisms to ensure that the wire is wound onto the spool with the appropriate tension. This is crucial for preventing wire tangling and maintaining spool integrity.


Applications of Straight Line Wire Drawing Machine


  • Automotive Industry: Straight line wire drawing machines are integral to the automotive sector for the production of wires used in various automotive components. The automotive industry demands wires with precise dimensions and high tensile strength, and wire drawing machines contribute to meeting these specifications.


  • Electrical Industry: In the electrical industry, where conductivity and reliability are paramount, straight-line wire drawing machines are extensively used. Straight-line wire drawing machines  contribute to the production of high-quality copper and aluminum wires used in electrical cables, conductors, and other electrical components.The precise diameter control and uniformity achieved by wire drawing machines are crucial for ensuring the efficient transmission of electrical signals.


  • Steel Industry: These straight line wire drawing machines play a vital role in shaping and refining steel wire, ensuring precise diameters and consistent properties. Our steel wire drawing machines can also meet the stringent requirements of various applications in the steel industry. The drawn steel wire is utilized in various applications, including construction, manufacturing of fasteners, and reinforcement in concrete structures.


  • Metal products industry: The rapid development of the metal products industry in recent years has led to an increased demand for straight line wire drawing machines  across various sub-sectors of metal processing. Wire drawing machines play a crucial role in this industry, offering essential capabilities for metal refinement and shaping.


Why Choose Rainbow as Your Straight Line Wire Drawing Machine Manufacturer?


Integrated Solutions:

Our Straight Line Wire Drawing Machine LZ9/1200 seamlessly integrates with the Spool Take-up Machine GS 1250, offering a complete solution for your wire processing needs.The straight line wire drawing machine is engineered for optimal wire diameter reduction, ensuring efficiency in the drawing process. The GS 1250 guarantees precise winding and packaging of the drawn wire. Experience enhanced productivity without compromising on quality.


High Productivity, Precise Control:

Benefit from high productivity levels while maintaining precise control over the wire drawing and winding processes. Our integrated solution empowers your operations with efficiency and accuracy.


Tailored to Your Needs:

We understand that different operations have unique requirements. Our straight line wire drawing machines are available in varied specifications, allowing you to choose a solution that perfectly fits your exact needs. As a reliable and innovative wire drawing machine manufacturer, we also provide premium belt wire drawing machine, fine copper wire drawing machine, combined drawing machine and so on.


Top-Notch Quality Components:

Manufactured by skilled professionals, Rainbow making machines are built with top-notch quality components, ensuring durability and reliability in every operation.


Timely Delivery via Extensive Network:

Our commitment to customer satisfaction extends to timely delivery. With an extensive distribution network, we ensure that our comprehensive wire drawing solution reaches you within the committed timeframe.


Choose us as your straight line wire drawing machine manufacturer and unlock a new era of efficiency, precision, and productivity. Elevate your manufacturing with our integrated solution today!
